IP65 Wallbox Electric Car Wall Box EV Charger 11kw 22KW IEC 62196

Product Categories
JIANGYIN TOPSUN TECH CO., LTD
Contact Now

IP65 Wallbox Electric Car Wall Box EV Charger 11kw 22KW IEC 62196

Brand Name : LINKIN

Rated current : 32A

Cable length : 5 Meters/ Customized

Package : Color Box

Connection : RFID Card

Protection Level : IP65

Input Voltage : 110-380V

Output Power : 7/11/22KW

Warranty : 36 Months

Contact Now

Business OCPP WIFI APP LEC 62196 Type 2 7KW 11KW 22KW 16A 32A AC Charging Station For Electric Vehicles

Power Specification


AC Power Input Rating
SAE Standard
IEC Standard
AC Level 2
1-Phase
3-Phase
110-220V ± 15%
110-220V ± 15%
110-380V ± 15%
AC Power Output Rating
7kW/32A
7kW/32A
11kW/16A
10kW/40A
N/A
22kW/32A
Rated Frequency
50/60Hz
50/60Hz
50/60Hz
Connector Type
SAE J1772 (Type 1)
IEC 62196-2 (Type 2)
User Interface & Control
Charging Control
Plug and Play, RFID Card or app,ocpp1.6
Display Screen
4.3-inch LCD Screen
Indicators
4 LED indicators-Power/Connect/Charging/Fault
Environmental
Storage Temperature
-40 to 75℃ (-40 to 167℉) ambient
Operating Temperature
-30 to 55℃ (-22 to 131℉) ambient
Operating Humidity
Up to 95% non-condensing
Altitude
≤2000m
Protection
Protection Ratings
IP 65
RCD
Type A / Type B
Over Voltage Protection
Yes
Under Voltage Protection
Yes
Over Load Protection
Yes
Short Circuit Protection
Yes
Earth Leakage Protection
Yes
Ground Protection
Yes
Over-temp Protection
Yes
Surge Protection
Yes
Wallbox Mechanical
Dimension (H x W x D, mm)
320 x 197 x 90MM
Weight
1-phase＜7kg; 3-phase＜8kg
Charging Cable Length
5m or Customize Length
Enclosure Material
Front-Panel: Tempered Glass; Back-cover: Metal Plate

Each charger will be fully inspection to ensure product performance in good condition:

Withstand voltage insulation test - start high voltage machine test
Charging preparation -- measuring input voltage
Charging connection confirmation - measuring resistance
Ready to charge - measure current
Ready to charge - measuring frequency
Start up and charging stage - measure the output voltage
Start up and charging phase - measuring output current
Normal charge end test - measure output voltage
CP Disconnection Test: measure the output voltage after resuming charging
CP ground test - measure output voltage
Input overvoltage protection - measure output voltage
Input overvoltage protection - automatic recovery function, measuring output voltage
Input undervoltage protection - measure output voltage
Input undervoltage protection - automatic recovery function, measuring output voltage
Leakage protection - measuring output voltage
Overcurrent protection - measuring output current
Over current protection - automatic recovery function, measuring output current
